Racking case studies. Measured before, counted after.

Six projects from workshops, plants and warehouses across South Wales. Each one starts with the numbers: pallet positions before and after, floor area recovered, how long the installation took and what downtime was avoided. Then the reasoning behind every line of the specification.

Case studies: 6
Sectors: 2
Towns: 6
Systems: 5

Every project.

Newest first. The photograph on each card is the installation described.

Double sided cantilever racking storing pipe and fittings

Cantilever tool and jig storage for an engineering workshop

Heavy tooling and jigs taken off the workshop floor and onto open-fronted cantilever arms, at pick height and craneable.

Swansea · 48 arm positions · 31% floor recovered

Read the case study

Indoor cantilever racking aisle storing plastic pipe

Long extrusion storage on cantilever racking

Six metre aluminium extrusions moved from floor stacks into a cantilever run, supported along their length so profiles stop bowing.

Neath · 168 arm positions · 38% floor recovered

Read the case study

Pallet racking aisle with boxed stock on timber decking

Carton live storage for a fast pick face

Inclined roller tracks bring cartons from the replenishment face to the pick face, so pickers stop walking to find stock.

Cardiff · 144 live lanes · 18% floor recovered

Read the case study

Single sided cantilever racking storing long plastic pipe against a wall

Coil racking with cradles for steel coil

Steel coil moved off the floor and onto shaped cradles that stop rolling and spread the point load, accessed by coil ram.

Newport · 72 cradle positions · 44% floor recovered

Read the case study

Pallet racking end frames with a load notice and footplate protectors

Heavy duty pallet racking for castings and tooling

Structural pallet racking specified for dense, heavy castings, with decking and load notices matched to the actual loads.

Llanelli · 384 rated positions · 22% floor recovered

Read the case study

Deep lane drive-in racking in a cold store

Wide aisle and drive-in racking for a mixed stock profile

A split layout: drive-in lanes for the bulk lines and wide aisle racking for everything else, specified from the stock profile rather than the floor area.

Port Talbot · 1,870 pallet positions · 27% floor recovered

Read the case study
